Technical Details
| Drill Diameter (\(d_{0}\)) | 16 mm |
|---|---|
| Thread Size | M16 |
| Total Anchor Length (\(l\)) | 218 mm to 220 mm (depending on the specific variant) |
| Min. Drill Hole Depth (\(h_{2}\)) | 204 mm for through fixings |
| Max. Usable Length (\(t_{fix}\)) | 100 mm (at standard anchorage depth) or up to 115 mm (at reduced anchorage depth) |
| Width Across Nut | 24 mm |
